| Color/Finish |
| Body |
Color |
Metallic Dark Gray |
| Size/Weight |
| Dimensions |
Width |
992 mm (39-1/16”) |
| Height |
136 mm (5-3/8”) |
| Depth |
404 mm (15-7/8”) |
| Weight |
Weight |
7.3 kg (16 lb, 1 oz) (not including batteries) |
| Control Interface |
| Keyboard |
Number of Keys |
61 |
| Touch Response |
Yes (Soft, Medium, Hard, Off) |
| Type |
Organ-style |
| Other Controllers |
Pitch Bend |
Yes |
| Modulation |
Yes |
| Art. Switches |
Yes |
| Control Knobs |
2 |
| Display |
Type |
LCD |
| Backlight |
Yes |
| Language |
English |
| Panel |
Language |
English |
| Voices |
| Tone Generation |
Tone Generating Technology |
AWM Stereo Sampling |
| Polyphony |
Number of Polyphony (Max.) |
64 |
| Preset |
Number of Voices |
927 (386 Voices + 43 Drum/SFXKits + 40 Arpeggio Voices + 458 XGlite Voices) |
| Featured Voices |
50 Indian Voices, 29 Super Articulation Lite Voices, 10 Sweet! Voices, 6 Cool! Voices, ３ Live! Voices |
| Compatibility |
GM |
Yes |
| XGlite |
Yes |
| Effects |
| Types |
DSP |
DSP1: 41 types, DSP2: 12 types |
| Reverb |
15 types |
| Chorus |
7 types |
| Master EQ |
6 types |
| Functions |
Dual/Layers |
Yes |
| Split |
Yes |
| Melody Suppressor |
Yes |
| Panel Sustain |
Yes |
| Accompaniment Styles |
| Preset |
Number of Preset Styles |
392 (Incl. Indian 70 Styles) |
| Fingering |
Multi Finger, Smart Chord |
| Style Control |
ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN(A, B)/Auto Fill, TRACK ON/OFF |
| Other Features |
Auto Chord Play |
135 Chord Progressions + 10 USER Chord Progressions |
| Expandability |
Expansion Style |
10 |
| Compatibility |
Style File Format (SFF) |
| Songs |
| Preset |
Number of Preset Songs |
75 |
| Recording |
Number of Songs |
10 |
| Number of Tracks |
6 (5 Melody + 1 Style) |
| Data Capacity |
Approx. 19,000 notes (when only “melody” tracks are recorded) |
| Compatible Data Format |
Playback |
SMF (Formats 0 & 1) |
| Recording |
Original File Format (SMF 0 conversion function) |
| USB Audio Recorder |
| Recording Time (max.) |
80 minutes (approx. 0.9 GB) per Song |
| Format |
Playback |
WAV (44.1 kHz, 16-bit, stereo) |
| Recording |
WAV (44.1 kHz, 16-bit, stereo) |
| Quick Sampling |
| Sampling Type |
Oneshot, Loop |
| Samples (Preset/User) |
4 |
| Sampling Time |
Approx. 9.6 sec |
| Sampling Sources |
AUX IN, MIC INPUT, USB audio interface, WAV format files |
| Sampling Format |
Original File Format (16-bit, stereo) |
| Sampling Rate |
44.1 kHz |
| Functions |
| Lesson/Guide |
Lesson/Guide |
Lesson 1–3 (Listening, Timing, Waiting), Repeat & Learn |
| Demo |
3 Demo Songs |
| USB audio interface |
44.1 kHz, 16-bit, stereo |
| Registration |
Number of Buttons |
4 (x 8 banks) |
| Control |
Freeze |
| Overall Controls |
Metronome |
Yes |
| Tempo Range |
11 – 280 (Tap Tempo: 32 – 280) |
| Transpose |
−12 – 0 – +12 |
| Tuning |
427.0 – 440.0 – 453.0 Hz (approx. 0.2 Hz increments) |
| Octave Button |
Yes |
| Scale Type |
5 |
| Riyaz (Tabla/Tanpura Pattern) |
Preset |
50 |
| Miscellaneous |
PIANO Button |
Yes (Harmonium/Piano) |
| Other Functions |
Mega Boost, Motion Effect (57 types), Looper |
| Voices |
Harmony/Echo |
26 types |
| Arpeggio |
182 types |
| Storage and Connectivity |
| Storage |
Internal Memory |
Approx. 1.72 MB |
| External Drives |
USB flash drive |
| Connectivity |
DC IN |
16 V |
| AUX IN |
Stereo mini jack |
| Headphones |
Standard stereo phone jack |
| Foot Switch |
Yes (Sustain, Arpeggio Hold, Sustain+Arpeggio Hold, Articulation, Sostenuto) |
| Foot Control |
Yes (Volume) |
| USB TO DEVICE |
USB type-A |
| USB TO HOST |
USB type-C™ |
| OUTPUT |
Standard stereo phone jacks: L/L+R, R |
| Microphone |
Standard mono phone jack |
| Amplifiers and Speakers |
| Amplifiers |
12 W + 12 W |
| Speakers |
12 cm x 2 |
| Power Supply |
| Power Supply |
AC Adaptor PA-300C, or six "AA" size alkaline (LR6), manganese (R6) or Ni-MH rechargeable (HR6) batteries |
| Power Consumption |
13 W (When using PA-300C AC adaptor) |
| Auto Power Off Function |
Yes（Disabled/5/10/15/30/60/120 minutes） |
| Accessories |
| Included Accessories |
Music Rest |
Yes |
| Song Book |
Download from Yamaha web site |
| Power Adaptor |
Yes |
