| Front Surround System |
| General |
Drivers |
Front speaker system: 5.5cm cone × 2, Subwoofer： 16cm cone woofer |
| Output Power |
160 W total power: 30 W x 2 (6ohms, 1kHz, 10 % THD) + 100 W subwoofer (5ohms, 100Hz, 10 % THD) |
| Power Consumption |
17W (Front speaker system), 45W (Subwoofer) |
| Standby Power Consumption |
≤2.0 W |
| Subwoofer |
bass-reflex (Advanced YST II with Linear Port) |
| Dimensions (W x H x D) |
886 X 98(without stands;80) X 121 mm (Front speaker system), 290 x 292 x 316 mm (Subwoofer) |
| Weight |
3.1 kg (Front speaker system), 8.3 kg (Subwoofer) |
| Input / Output |
Digital Optical |
2 in |
| Sound Technology |
Surround Technology |
AIR SURROUND XTREME |
| UniVolume |
Yes |
| Clear Voice |
Yes |
| Audio Formats |
Dolby Digital |
Yes |
| Dolby Pro Logic II |
Yes |
| DTS |
Yes |
| Extensive Connection |
Wireless Subwoofer |
Yes |
| Wireless Compatibility via Yamaha Wireless Transmitter |
Yes (iPod/iPhone/iPad or Mac/PC via optional YIT-W12) |
| Other Features |
Other Features |
TV Remote Repeater, Learning function |
