| AV Receiver |
| Amplifier Section |
Channel |
5.1 |
| Rated Output Power (1kHz, 1ch driven) |
105W (6ohms, 0.9% THD) |
| Dynamic Power per Channel (8/6/4/2 ohms) |
-/110/130/150W |
| Surround Sound Processing |
CINEMA DSP |
Yes |
| DSP Programs |
17 |
| SILENT CINEMA / Virtual CINEMA DSP |
Yes |
| Dolby TrueHD |
Yes |
| Dolby Digital Plus |
Yes |
| Dolby Pro Logic IIx |
Yes |
| DTS-HD Master Audio |
Yes |
| Audio Features |
Compressed Music Enhancer |
Yes |
| YPAO sound optimization |
Yes |
| Adaptive DRC (Dynamic Range Control) |
Yes |
| Initial Volume & Maximum Volume Setting |
Yes |
| Audio Delay |
Yes（0-240 ms） |
| 192kHz/24-bit DACs for all channels |
Yes (Burr Brown) |
| Video Features |
HDMI 3D passthrough |
Yes |
| HDMI Audio Return Channel |
Yes |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync |
Yes |
| Extensive Connection |
HDMI Input/Output |
4 / 1 |
| HDMI CEC |
Yes |
| Dock Port |
1 (YDS-12) |
| Front AV Input |
Mini Jack/Analog Audio/Composite |
| Digital Audio Input/Output: Optical |
2 / 0 |
| Digital Audio Input/Output: Coaxial |
2 / 0 |
| Analog Audio Input/Output |
5 (front 1) / 2 |
| Component Video Input/Output |
2 / 1 |
| Composite Video Input/Output |
5 (front 1) / 1 |
| Preout |
SW/Surround Back |
| Headphone Output |
1 |
| Tuner Section |
FM/AM Tuner |
Yes |
| User Interface |
SCENE |
SCENE (4 sets) |
| Remote Control Unit |
Preset |
| General |
Standby Power Consumption (IR only) |
≤0.2W |
| Auto Power Standby |
Yes |
| Dimensions (W x H x D) |
435x151x364mm |
| Weight |
8.4kg |
| Audio Technical Specifications |
Total Harmonic Distortion |
0.06% |
| Signal-to-Noise Ratio |
100 dB (Direct, 250 mV) |
| Package Speaker |
| Channel |
5.1 |
| Speaker System |
System Frequency Response |
30 Hz–25 kHz |
| Impedance |
6 ohms (without subwoofer) |
| Front Speaker |
Type |
Full-range bass-reflex |
| Driver |
7 cm full-range cone |
| Nominal Input Power |
30 W |
| Maximum Input Power |
100 W |
| Sensitivity |
83 dB/2.83 V/1 m |
| Dimensions (W x H x D) |
112 x 176 x 116 mm |
| Weight |
0.59 kg / unit |
| Center Speaker |
Type |
Full-range acoustic suspension |
| Driver |
7cm full-range cone |
| Nominal Input Power |
30 W |
| Maximum Input Power |
100 W |
| Sensitivity |
84 dB/2.83 V/1 m |
| Dimensions (W x H x D) |
276 x 111 x 118 mm |
| Weight |
0.73 kg |
| Surround Speaker |
Type |
Full-range bass-reflex |
| Driver |
7 cm full-range cone |
| Nominal Input Power |
30 W |
| Maximum Input Power |
100 W |
| Sensitivity |
83 dB/2.83 V/1 m |
| Dimensions (W x H x D) |
112 x 176 x 116 mm |
| Weight |
0.59 kg / unit |
| Subwoofer |
Type |
Advanced YST II with Linear Port |
| Driver |
16cm cone |
| Output Power |
50 W (5 ohms, 100 Hz, 10% THD) |
| Dynamic Power |
100 W |
| Dimensions (W x H x D) |
290 x 292 x 327 mm |
| Weight |
8 kg |
