| RX-V567 | ||
|---|---|---|
| Amplifier Section | Channel | 7.1 |
| Rated Output Power (1kHz, 1ch driven) | 90W (8ohms, 0.9% THD) | |
| Dynamic Power per Channel (8/6/4/2 ohms) | 95/110/130/150W | |
| Surround Sound Processing | CINEMA DSP | Yes |
| DSP Programs | 17 | |
| SILENT CINEMA / Virtual CINEMA DSP | Yes | |
| Dolby TrueHD | Yes | |
| Dolby Digital Plus | Yes | |
| Dolby Pro Logic IIx | Yes | |
| DTS-HD Master Audio | Yes | |
| Audio Features | Pure Direct | Yes |
| Compressed Music Enhancer | Yes | |
| YPAO sound optimization | Yes | |
| Adaptive DRC (Dynamic Range Control) | Yes | |
| Initial Volume & Maximum Volume Setting | Yes | |
| Bi-amp capability | Yes | |
| Audio Delay | Yes（0-240 ms） | |
| 192kHz/24-bit DACs for all channels | Yes (Burr Brown) | |
| Video Features | HDMI 3D passthrough | Yes |
| HDMI Audio Return Channel | Yes | |
| HDMI upscaling | Analog to HDMI | |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync | Yes | |
| Extensive Connection | HDMI Input/Output | 4 / 1 |
| HDMI CEC | Yes | |
| Dock Port | 1 (YDS-12, YBA-10) | |
| Front AV Input | Mini Jack/Analog Audio/Composite | |
| Digital Audio Input/Output: Optical | 2 / 0 | |
| Digital Audio Input/Output: Coaxial | 2 / 0 | |
| Analog Audio Input/Output | 5 (front 1) / 2 | |
| Component Video Input/Output | 2 / 1 | |
| S-Video Input/Output | 1 / 0 | |
| Composite Video Input/Output | 5 (front 1) / 1 | |
| Preout | SW | |
| Headphone Output | 1 | |
| Tuner Section | FM/AM Tuner | Yes |
| User Interface | On-screen display | OSD (Text) |
| SCENE | SCENE (4 sets) | |
| Remote Control Unit | Preset | |
| General | Standby Power Consumption (IR only) | ＜0.2W |
| Auto Power Standby | Yes | |
| Dimensions (W x H x D) | 435x151x364mm | |
| Weight | 8.5kg | |
| Audio Technical Specifications | Total Harmonic Distortion | 0.06% |
| Signal-to-Noise Ratio | 100 dB (Direct, 250 mV) | |
