Speaker General Bracket

General Bracket

BWS20-120 Wall Mounting brackets

  • Net weight: 0.6kg; 1.3lbs
  • Load capability: 7kg; 15.4lbs
  • Applicable for: VXS5, S55, S15, HS5I, MSP3, MS101III

BWS20-190 Wall Mounting brackets

  • Net weight: 0.85kg; 1.9lbs
  • Load capability: 7kg; 15.4lbs
  • Applicable for: VXS5, S55, S15, HS5I, MSP3, MS101III

BCS20-150 Ceiling Bracket

  • Net weight: 0.9kg; 2lbs
  • Load capability: 10kg; 22.1lbs
  • Applicable for: VXS8, VXS5, S55, S15, HS5I, MSP5 STUDIO, MSP3, MS101III

BCS20-210 Ceiling Bracket

  • Net weight: 1.0kg; 2.2lbs
  • Load capability: 10kg; 22.1lbs
  • Applicable for: VXS8, VXS5, S55, S15, HS5I, MSP5 STUDIO, MSP3, MS101III

BWS50-190 Wall Mounting Bracket

  • Net weight: 1.2kg; 2.6lbs
  • Load capability: 20kg; 44.1lbs
  • Applicable for: HS8I, HS7I, MSP7 STUDIO

BWS50-260 Wall Mounting Bracket

  • Net weight: 1.4kg; 3.1lbs
  • Load capability: 20kg; 44.1lbs
  • Applicable for: HS8I, HS7I, MSP7 STUDIO

BBS251 Baton Bracket

  • Net weight: 2.3kg; 5.1lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BWS251-300 Wall Mounting Bracket

  • Net weight: 4.4kg; 9.7lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BWS251-400 Wall Mounting Bracket

  • Net weight: 5.2kg; 11.5lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BCS251 Ceiling Bracket

  • Net weight: 2.3kg; 5.1lbs
  • Load capability: 30kg; 66.2lbs
  • Applicable for: IF2208, IF2108, IF2205, CBR15, CBR12, CBR10, DBR15, DBR12, DBR10, C112VA, HS8I, HS7I

BAS-10

Free-Angle Clamp

  • Net weight: 0.75kg; 1.6lbs / Load capability: 4kg; 8.8lbs
  • Applicable for: MSP3, MS101III, S15

BMS-10A Mic Stand Adaptor

  • Net weight: 0.24kg; 0.5lbs / Load capability: 5kg; 11.0lbs
  • Applicable for:  MSP3, MS101III, S15, STAGEPAS 400i, STAGEPAS 600i, STAGEPAS 400BT, STAGEPAS 600BT

For DZR/CZR Series

UB-DZR15V U-Brackets

U-brackets enabling simple and easy rigging in vertical configurations. (for DZR15/15-D, CZR15)

  • Net weight: 5.9kg; 13.0lbs
  • Applicable for: DZR15/15-D, CZR15

UB-DZR15H U-Brackets

U-brackets enabling simple and easy rigging in horizontal configurations. (for DZR15/15-D, CZR15)

  • Net weight: 6.2kg; 13.7lbs
  • Applicable for: DZR15/15-D, CZR15

UB-DZR12V U-Brackets

U-brackets enabling simple and easy rigging in vertical configurations. (for DZR12/12-D, CZR12)

  • Net weight: 4.7kg; 10.4lbs
  • Applicable for: DZR12/12-D, CZR12

UB-DZR12H U-Brackets

U-brackets enabling simple and easy rigging in horizontal configurations. (for DZR12/12-D, CZR12)

  • Net weight: 4.7kg; 10.4lbs
  • Applicable for: DZR12/12-D, CZR12

UB-DZR10V U-Brackets

U-brackets enabling simple and easy rigging in vertical configurations. (for DZR10/10-D, CZR10)

  • Net weight: 3.6kg; 7.9lbs
  • Applicable for: DZR10/10-D, CZR10

UB-DZR10H U-Brackets

U-brackets enabling simple and easy rigging in horizontal configurations. (for DZR10/10-D, CZR10)

  • Net weight: 3.8kg; 8.4lbs
  • Applicable for: DZR10/10-D, CZR10

For DXR Series

UB-DXR15 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations. (for DXR15)

UB-DXR12 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations. (for DXR12)

UB-DXR10 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations. (for DXR10)

UB-DXR8 U-Brackets

U-brackets allow simple and easy rigging in both horizontal and vertical configurations. (for DXR8)

For Installation Series

HAF3-2112 Horizontal Array Frame for 3 Speakers

  • Available for: IF2112(M)/95/64/99×3
  • Net weight: 9kg

HAF3-2115 Horizontal Array Frame for 3 Speakers

  • Available for: IF2115(M)/95/64/99×3
  • Net weight: 10kg

HAF3-3115 Horizontal Array Frame for 3 Speakers

  • Available for: IF3115/95/64×3, IH2000/95/64×3, IH2000/95/64×2 and IL1115×1, IH2000/95/64×1 and IL1115×2, IL1115×3
  • Net weight: 14kg

HAF3-S18 Horizontal Array Frame for 3 Speakers

  • Available for: IF3115/95/64×2 and IS1218×1, IH2000/95/64×2 and IS1118×1
  • Net weight: 29kg

HAF2-2112 Horizontal Array Frame for 2 Speakers

  • Available for: IF2112(M)/95/64/99×2
  • Net weight: 4kg

HAF2-2115 Horizontal Array Frame for 2 Speakers

  • Available for: IF2115(M)/95/64/99×2
  • Net weight: 5kg

HAF2-3115 Horizontal Array Frame for 2 Speakers

  • Available for: IF3115/95/64×1, IH2000/95/64×1 and IL1115×1
  • Net weight: 6kg

VAF2-2112 Vertical Array Frame for 2 Speakers

  • Available for: IF2112(M)/95/64/99×2
  • Net weight: 4kg

VAF2-2115 Vertical Array Frame for 2 Speakers

  • Available for: IF2115(M)/95/64/99×2
  • Net weight: 5kg

VAF2-3115 Vertical Array Frame for 2 Speakers

  • Available for: IF3115/95/64×2, IH2000/95/64×2
  • Net weight: 6kg

UB2112 U-Brackets

  • Available for: IF2112(M)/95/64/99/AS
  • Net weight: 4kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2115 U-Brackets

  • Available for: IF2115(M)/95/64/99/AS
  • Net weight: 9kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2000 U-Brackets

  • Available for: IH2000/95/64, IL1115
  • Net weight: 9kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2208 U-Brackets

  • Available for: IF2208
  • Net weight: 3kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2108 U-Brackets

  • Available for: IF2108
  • Net weight: 2kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

UB2205 U-Brackets

  • Available for: IF2205
  • Net weight: 1kg
  • * The bracket for the UB series is designed to be used horizontally. It cannot be used vertically.

The colors and finishes shown may vary from those on the actual products.
